Wall system

Double Wall Track
80 kg/m

The Double Wall Track offers a smart and discreet way to hang artwork, ideal for museums and exhibition spaces.

Double Wall Track (Colour): WHITE RAL9010

Product variants

Buy this product directly online or find a store near you.

€73,²⁷/ each

Business inquiry

Business inquiry Find a store nearby Contact us

Description

The Double Wall Track is a two-part rail system for museums and exhibition spaces: a base rail that attaches directly to the wall and a cover that conceals the rail and sliding sections. This ensures a sleek finish and secure, reversible mounting without causing additional damage to the wall. Standard in RAL 9010 white ; other RAL colors are available upon request (additional charge) or can be painted over (special cover).

The Double Wall Track has a load capacity of 80 kg per meter. This makes it a reliable, safe, and convenient hanging system for larger and heavier artworks.

Mounting set is included: 9x screws and 9x plugs.

Specifications

Load capacity	80 kg/m
Height piece (mm)	12
Width piece (mm)	38
Length piece (mm)	2000
Material	Aluminum
Type	Wall rail
Article number	TS00001

Download

T s installation sheet double wall track hr PDF Document

Download

Technical sheet double wall track PDF Document

Download

Product catalogue PDF Document

Download

Track slide product catalogue en lr v3 spread PDF Document

Download

Product warranty PDF Document

Download

Technical specifications

Geen downloads beschikbaar voor dit product.

Hang art reliably and securely

The Double Wall Track works with a special slider which is easy to any desired location in the rail is crocheted and can be secured.

The Slider is only compatible with 1.2 and 1.8 mm steel wire. Slide the 1.2 or 1.8 mm steel wire through the Slider and combine it with the Auto Grip Lock hook for hanging artwork from 15 to 40 kg (max. weight depends on the type of steel wire).

See below for the installation steps for the Double Wall Track and how the Slider is attached and secured to the rail.
